Unreal Engine Integration

Assets

Our simulator provides a rich collection of city-scale assets, designed to support realistic and diverse urban simulations. These assets include buildings, trees, street furniture, vehicles, pedestrians, and robots. All assets are sourced from the Unreal Engine Marketplace to ensure high visual fidelity and performance.

In addition to the curated asset library, we also offer an Asset Generation Pipeline that enables users to create .uasset files directly from natural language descriptions. This tool streamlines the content creation process by converting user prompts into usable Unreal Engine assets, significantly lowering the barrier for customizing city environments.

Collected Assets

Below is a selection of the assets currently available in our simulator:

Buildings: A variety of architectural styles, including residential, commercial, and industrial structures.
Trees: Multiple tree species with seasonal variations to enhance environmental realism.
Street Furniture: Items such as benches, streetlights, boxes, and trash bins to add detail and immersion.
Vehicles: A range of vehicles including cars, buses, trucks, and scooters, each with accurate scale and animations.
Pedestrians: Human characters with diverse appearances and animations to simulate crowd behavior.
Robots: Different types of mobile robots for testing autonomous navigation and interaction, such as humanoid and robot dog.

These assets collectively enable the creation of complex, dynamic, and realistic city scenes for simulation, visualization, and research purposes.

Asset Generation Pipeline

Our Asset Generation Pipeline enables the automatic generation of 3D assets from natural language descriptions. This tool is currently designed for developers and is intended to be used within the Unreal Engine Editor. By translating descriptive text into .uasset files, this pipeline significantly accelerates asset creation, making it easier to populate large-scale environments with customized elements.

Warning

Asset Generation Pipeline can only be used in editor mode.

Actions

To enhance realism and interactivity in the simulation, we provide a comprehensive set of Action Space, with a strong focus on animations for pedestrians and robots. These actions are essential for simulating lifelike behaviors such as walking, running, waving, interacting with objects, and more. All actions are sourced from the Unreal Engine Marketplace to ensure quality and compatibility.

Here are some examples of actions available in the simulator:

Action	Agent Type	Category	Description
Move Forward	Humanoid	Navigation	Keep moving in the current direction
Directional Step	Robot	Navigation	Step in a specified direction briefly
Hold Position	Robot	Navigation	Stay motionless for a short time
Step Forward/Backward	Humanoid	Navigation	Step forward/backward for a fixed time
Rotate	Humanoid, Robot	Navigation	Turn the body to face a new direction
Stop	Humanoid	Navigation	Stop moving
Look Up/Down	Humanoid, Robot	Observation	Adjust the gaze upward/downward by a degree
Focus	Humanoid, Robot	Observation	Adjust the field of view
Pick Up	Humanoid	Object Interaction	Grasp and lift an object
Drop Off	Humanoid	Object Interaction	Release a held object at the target location
Set Throttle/Brack/Steering	Vehicle	Driving	Control a vehicle
Sit Down	Humanoid	Object Interaction	Transition to a seated position
Stand Up	Humanoid	Object Interaction	Rise from a seated position
Enter Car	Humanoid	Object Interaction	Get into a vehicle
Exit Car	Humanoid	Object Interaction	Leave a vehicle
Get On Scooter	Humanoid	Object Interaction	Get on a scooter
Get Off Scooter	Humanoid	Object Interaction	Get off a scooter
Have Conversation	Humanoid	Social Action	Exchange verbal communication
Point Direction	Humanoid	Social Action	Gesture to indicate direction
Wave Hand	Humanoid	Social Action	Signal or greet with a hand wave
Discuss	Humanoid	Social Action	Engage in dialogue or explanation
Argue with Body Language	Humanoid	Social Action	Express disagreement using gestures

Demo for human action space

# Initialize a humanoid agent with position (0, 0) and facing direction (1, 0)
humanoid = Humanoid(Vector(0, 0), Vector(1, 0))
humanoid_name = 'GEN_BP_Humanoid_0'

# Spawn the humanoid in the simulator using the specified model path
communicator.spawn_agent(humanoid, humanoid_model_path)

# Make the humanoid sit down
ucv.humanoid_sit_down(humanoid_name)

# Make the humanoid stand up
ucv.humanoid_stand_up(humanoid_name)

# Play an "argue" animation (the number may represent the type or intensity)
ucv.humanoid_argue(humanoid_name, 0)

# Play a "discuss" animation
ucv.humanoid_discuss(humanoid_name, 0)

# Play a "listening" animation
ucv.humanoid_listen(humanoid_name)

# Make the humanoid point or gesture along a path
ucv.humanoid_directing_path(humanoid_name)

# Play a waving gesture directed toward a dog
ucv.humanoid_wave_to_dog(humanoid_name)

# Make the humanoid pick up an object (e.g., a mug)
ucv.humanoid_pick_up_object(humanoid_name, "BP_Mug_C_1")

# Drop the currently held object
ucv.humanoid_drop_object(humanoid_name)

# Command the humanoid to enter a specific vehicle
ucv.humanoid_enter_vehicle(humanoid_name, "BP_VehicleBase_Destruction_C_1")

# Command the humanoid to exit that vehicle
ucv.humanoid_exit_vehicle(humanoid_name, "BP_VehicleBase_Destruction_C_1")

# Create a scooter object at position (100, 0) facing direction (0, 1)
scooter = Scooter(Vector(100, 0), Vector(0, 1))

# Spawn the scooter into the simulation
communicator.spawn_scooter(scooter, scooter_path)

# Make the humanoid get on the scooter
communicator.humanoid_get_on_scooter(agent.id)

# Set scooter attributes: speed = 0.5, direction = 0, angular velocity = 0
communicator.set_scooter_attributes(agent.scooter_id, 0.5, 0, 0)

# Make the humanoid get off the scooter
communicator.humanoid_get_off_scooter(agent.id, scooter.id)

# Make the humanoid step forward for 2 seconds
communicator.humanoid_step_forward(agent.id, 2)

# Rotate the humanoid 90 degrees to the left
communicator.humanoid_rotate(agent.id, 90, 'left')

# Start continuous forward movement
communicator.humanoid_move_forward(agent.id)

# Stop movement, optionally play a stop animation for 2 seconds
communicator.humanoid_stop(agent.id, 2)

Demo for robot action space

# Specify robot name and asset
robot_name = "Demo_Robot"
robot_asset = "/Game/Robot_Dog/Blueprint/BP_SpotRobot.BP_SpotRobot_C"

# Spawn robot in the simulator
ucv.spawn_bp_asset(robot_asset, robot_name)
ucv.enable_controller(robot_name, True)

# Robot - look up / look down
ucv.dog_look_up(robot_name)    # look up
ucv.dog_look_down(robot_name)  # look down

# Robot Movement
# direction: 0 = forward, 1 = backward, 2 = left, 3 = right
for direction in [0, 1, 2, 3]:
    speed = 200
    duration = 1
    move_parameter = [speed, duration, direction]
    ucv.dog_move(robot_name, move_parameter)
    time.sleep(duration)

# Robot Rotation
# clockwise: 1 = right turn, -1 = left turn
for angle, clockwise in [(90, 1), (-90, -1)]:
    duration = 0.7
    rotate_parameter = [duration, angle, clockwise]
    ucv.dog_rotate(robot_name, rotate_parameter)
    time.sleep(duration)

Related files: communicator.py, unrealcv.py.

A complete example can be found in scripts/ue_command_test.ipynb.

Sensors

As illustrated in the figure above, SimWorld supports a variety of sensors, including RGB images, segmentation maps, and depth images, enabling a rich understanding of the surrounding environment.

How to get images

# viewmode can be 'lit', 'depth' and 'object_mask'
image = communicator.get_camera_observation(camera_id, viewmode)

# adjust camera
ucv.get_cameras()
ucv.get_camera_location(camera_id)
ucv.get_camera_rotation(camera_id)
ucv.get_camera_fov(camera_id)
ucv.get_camera_resolution(camera_id)
ucv.set_camera_location(camera_id)
ucv.set_camera_rotation(camera_id)
ucv.set_camera_fov(camera_id)
ucv.set_camera_resolution(camera_id)

Related files: communicator.py, unrealcv.py.

Synchronous and Asynchronous mode

Our simulator supports both synchronous and asynchronous execution modes for communication between the Python client and the Unreal Engine (UE) server.

In synchronous mode, the Python client explicitly controls the simulation timing. At each step, it sends a tick command to the UE server and waits until the server completes the simulation update. This mode ensures deterministic behavior, which is especially important for reinforcement learning, multi-agent coordination, and evaluation tasks.

In asynchronous mode, the UE server runs continuously at its own frame rate, while the Python client retrieves data at any time. This allows for real-time interaction but can lead to non-determinism and race conditions in agent-environment interaction.

# Set simulation mode: choose between "sync" (synchronous) and "async" (asynchronous)
mode = "sync"
tick_interval = 0.05  # Duration of each simulation step in seconds (only used in sync mode)
ucv.set_mode(mode, tick_interval)

# Advance the simulation by one tick (tick_interval seconds)
ucv.tick()
